Fault Tree Analysis vs Event Tree Analysis

When you go beyond a basic HAZOP, two tools appear again and again: Fault Tree Analysis (FTA) and Event Tree Analysis (ETA).
You can think of them as:

  • FTA – works backwards from an accident to find causes.
  • ETA – works forwards from a failure to show possible outcomes.
    This article explains:
  • How each technique works with practical examples.
  • When to use FTA vs ETA in South African MHI assessments.
  • How they combine in LOPA and SIL studies.
  • Typical costs for these studies in Rand.

Fault Tree Analysis (FTA): The Detective (Top-Down)

Direction: Top-Down (Deductive)
Question: "Why did this happen?"
FTA starts with the Top Event (the disaster, e.g., "Tank Explosion") and works backward to find the root causes. It uses logic gates (AND / OR) to combine failures.

How it Works

  1. Top Event: Fire in Storage Tank.
  2. Logic: The fire happens IF (Fuel is present) AND (Ignition Source is present).
  3. Drill Down:
  • Fuel present IF (Leak occurred) OR (Spill occurred).
  • Ignition source IF (Static spark) OR (Maintenance work) OR (Lightning).

FTA Logic Gates

Gate Symbol Meaning
AND All inputs must occur for output to occur
OR Any input can cause the output

When to Use FTA

  • When you want to find the Probability of Failure of a specific system.
  • When investigating an accident (Root Cause Analysis).
  • When analysing complex control systems where multiple things must fail simultaneously.
  • When calculating SIL (Safety Integrity Level) for safety instrumented functions.

SA Industry Example

Scenario: Ammonia release at a cold storage facility (Tiger Brands, RCL Foods).
Top Event: Ammonia release to atmosphere.
FTA branches:

  • Pipe rupture (OR: corrosion, mechanical damage, overpressure)
  • Valve failure (OR: stuck open, seal leak, operator error)
  • Vessel failure (OR: fatigue, external impact, design flaw)
    Each branch is assigned a failure rate from databases (IOGP, OREDA) to calculate the overall probability of the top event.

Event Tree Analysis (ETA): The Futurist (Bottom-Up)

Direction: Bottom-Up (Inductive)
Question: "What happens next?"
ETA starts with an Initiating Event (a failure, e.g., "Pipe Leak") and works forward to determine the possible outcomes (consequences). It looks at the success or failure of your safeguards (Barriers).

How it Works

  1. Initiating Event: Gas Pipe Leak.
  2. Barrier 1: Gas Detection System? (Success: Alarm / Failure: No Alarm).
  3. Barrier 2: ESD Valve? (Success: Flow Stops / Failure: Flow Continues).
  4. Barrier 3: Ignition? (Yes: Explosion / No: Safe Dispersion).
    Each path through the tree has a calculated frequency, and each end state has a defined consequence.

When to Use ETA

  • When you want to understand the different Consequences of a single failure.
  • When evaluating the effectiveness of your protection layers (LOPA).
  • To determine the frequency of different accident scenarios for a Quantitative Risk Analysis (QRA).
  • When designing emergency response procedures.

SA Industry Example

Scenario: LPG leak at a bulk depot (Easigas, Afrox, Oryx).
Initiating Event: 50 mm flange leak on LPG transfer line.

Barrier Success Failure
Gas detection Alarm raised No alarm
ESD activation Flow isolated Flow continues
Ignition No ignition (safe dispersion) Ignition (VCE or flash fire)
Outcome frequencies:
  • Safe dispersion: 60% of scenarios
  • Flash fire: 25% of scenarios
  • VCE (Vapour Cloud Explosion): 15% of scenarios
    These frequencies feed directly into the QRA risk contour calculation.

The "Bow-Tie" Diagram: Putting Them Together

In modern risk management, we often combine FTA and ETA into a Bow-Tie Diagram:

[Causes] → [FTA] → [TOP EVENT] → [ETA] → [Consequences]
                       ↑
                  (Loss of Containment)
  • The Fault Tree is on the left (Causes leading to the Event).
  • The Event (Loss of Containment) is the knot in the centre.
  • The Event Tree is on the right (Consequences flowing from the Event).

Why Bow-Tie is Popular in SA

Many South African facilities (Sasol, Engen, AECI, Anglo American) use Bow-Tie diagrams because:

  • They provide a visual summary of risk that management can understand.
  • They clearly show prevention barriers (left side) and mitigation barriers (right side).
  • They support barrier management programmes required under MHI Regulations.

LOPA: The Bridge Between Qualitative and Quantitative

Layer of Protection Analysis (LOPA) is a semi-quantitative technique that uses simplified event trees to determine if existing safeguards are sufficient.

How LOPA Works

  1. Start with an Initiating Event frequency (e.g., 1×10⁻² per year for a pump seal failure).
  2. Apply Independent Protection Layers (IPLs) – each IPL reduces the frequency by a factor (typically 10× to 100×).
  3. Calculate the Mitigated Event Frequency.
  4. Compare to the Risk Tolerance Criteria.

LOPA in South Africa

LOPA is widely used in SA for:

  • SIL determination – deciding what SIL rating a Safety Instrumented Function (SIF) needs.
  • Safeguard credit validation – proving that existing barriers are sufficient.
  • Cost-benefit analysis – justifying the cost of additional safeguards.
    Relevant standards:
  • IEC 61511 – Functional safety for the process industry.
  • SANS 61511 – South African adoption of IEC 61511.

Typical LOPA Costs in South Africa

Scope Typical Cost (excl. VAT)
Single scenario LOPA R20 000 – R40 000
LOPA workshop (10–20 scenarios) R80 000 – R150 000
Full facility LOPA (50+ scenarios) R200 000 – R400 000

SIL Studies: When FTA Gets Serious

When a LOPA identifies that a Safety Instrumented System (SIS) is required, you need to determine the Safety Integrity Level (SIL).

SIL Ratings

SIL Risk Reduction Factor Probability of Failure on Demand (PFD)
SIL 1 10–100 0.1 – 0.01
SIL 2 100–1 000 0.01 – 0.001
SIL 3 1 000–10 000 0.001 – 0.0001
SIL 4 10 000–100 000 0.0001 – 0.00001

SIL Verification

Once a SIL target is set, FTA is used to verify that the proposed SIS design can achieve the required PFD. This involves:

  • Modelling the SIS architecture (1oo1, 1oo2, 2oo3, etc.).
  • Assigning failure rates to each component.
  • Calculating the overall PFD using FTA.

Typical SIL Study Costs in South Africa

Study Type Typical Cost (excl. VAT)
SIL determination (per SIF) R15 000 – R30 000
SIL verification (per SIF) R20 000 – R50 000
Full SIS lifecycle study R100 000 – R300 000

Key Differences at a Glance

Aspect Fault Tree Analysis (FTA) Event Tree Analysis (ETA)
Direction Backward (Deductive) Forward (Inductive)
Starting Point Top Event (accident) Initiating Event (failure)
Focus Causes of an event Consequences of an event
Logic AND / OR Gates Success / Failure Paths
Output Probability of Top Event Frequency of each outcome
Best For Finding probability of complex failures Analysing barrier effectiveness
SA Application SIL verification, incident investigation QRA, LOPA, emergency planning

When to Use Each Technique

Use FTA When:

  • You need to calculate the probability of a specific failure (e.g., SIS fails to act).
  • You are investigating an incident and need to find root causes.
  • You are designing a safety system and need to verify it meets SIL requirements.
  • You have a complex system with multiple redundant components.

Use ETA When:

  • You need to understand all possible outcomes of a single failure.
  • You are conducting a QRA and need scenario frequencies.
  • You are evaluating the effectiveness of barriers (LOPA).
  • You are developing emergency response procedures and need to know what could happen.

Use Both (Bow-Tie) When:

  • You want a complete picture of risk for a major hazard.
  • You need to communicate risk to management or regulators.
  • You are implementing a barrier management programme.

Common Pitfalls in South Africa

Based on our experience:

  • Using generic failure rates without validation – SA operating conditions may differ from European/US data.
  • Ignoring common cause failures – if two "independent" barriers share a power supply, they're not truly independent.
  • Over-crediting human intervention – operators under stress may not respond as assumed.
  • Not updating FTA/ETA after changes – MoC should trigger a review.
  • Confusing SIL target with SIL achieved – you must verify the design meets the target.

Conclusion

Both FTA and ETA are essential for a complete understanding of risk:

  • FTA helps you prevent the accident from starting (prevention).
  • ETA helps you mitigate the impact if it does start (mitigation).
    Together, they form the backbone of modern process safety analysis, from LOPA and SIL studies to full QRA.
