Use this printable HAZOP guide-word reference to prompt questions about deviations from design intent. The examples are illustrative; select guide words for the study scope and process.

HAZOP guide words prompt a team to examine how a process or operation could deviate from its design intent. The study team applies relevant guide-word and parameter combinations, then records plausible causes, consequences, safeguards and actions. A guide word is a prompt, not proof that a deviation is credible or that the study covered every hazard.
The IEC 61882 application guide includes examples of basic guide words and additional terms for time and sequence. The relevant combination depends on the node, design intent, parameter and study scope. This reference is a discussion aid, not a compliance certificate or substitute for the applicable standard and competent facilitation.

Core guide words and example interpretations

Guide word General meaning Illustrative process prompt
NO / NOT None of the intended function occurs No cooling-water flow
MORE A quantitative increase More flow or higher temperature than intended
LESS A quantitative decrease Less flow than intended
AS WELL AS Something additional is present Water is present as well as the intended material
PART OF Only part of the intention is achieved Only part of the intended transfer occurs
REVERSE The logical opposite of the intention Flow goes in the opposite direction
OTHER THAN A different result or material occurs A different material is transferred
These examples are hypothetical. For each relevant combination, define the deviation in relation to the agreed design intent. Do not assume that a guide word applies to every parameter or node.

Time and sequence prompts

IEC 61882 also gives examples of EARLY and LATE for clock time, and BEFORE and AFTER for order or sequence. For example, a batch step might occur earlier or later than intended, or a transfer step might occur before or after another required step. Teams may define additional guide words before the examination when they help identify deviations in the system being studied.

How to use the reference during a study

  1. Agree the study boundary, node and design intent.
  2. Select parameters and guide words that make sense for that intent and operating mode.
  3. Describe one deviation clearly, then discuss credible causes and consequences.
  4. Record safeguards and recommendations according to the study method.
  5. Explain why a guide-word combination was included or excluded when that decision affects coverage.
    A cooling-water example can help explain the method: for a node with cooling-water flow as a parameter, “NO flow” may prompt discussion of a blocked line or unavailable pump. These are brainstorming possibilities only; a site team must check its own P&IDs, operating conditions, causes, consequences and safeguards before recording a finding.

What the card does not establish

The card does not prescribe a universal number of guide words, a fixed session duration or a mandatory order for every study. It does not prove SANS 1461 compliance or guarantee a complete HAZOP. South African MHI risk assessments must follow Regulation 10 and SANS 1461; confirm the applicable method requirements against the standard and approved inspection authority's scope.

Frequently asked questions

Should a team apply every guide word to every parameter?

Not automatically. Apply guide words that can meaningfully test the agreed design intent and parameter. Record relevant exclusions and the reason when it affects study coverage.

Are EARLY, LATE, BEFORE and AFTER additional examples?

Yes. IEC 61882 gives them as examples for clock-time and order or sequence deviations. Additional guide words can be selected when they suit the study, provided the team agrees them before examination.

Is this reference card a PDF?

The downloadable resource is a printable HTML page. Use its print control to save a PDF if that format suits your workshop.

Download the printable reference

Open the HAZOP Guide Words Reference Card and choose Print / Save as PDF if you need a local copy. Check the page and print preview before sharing it with a workshop team.
For broader context, read the HAZOP study guide, HAZOP guide-word explanations, and guide to defining study nodes.
